Hospital Hot Water System Solution

Medical venues impose extremely high standards on water temperature, water quality and continuous water supply. The complete hot water system takes high-temperature air source heat pumps as the core heat source with constant hot water output of 55-60°C. Ultra-low temperature jet enthalpy increase units are optional for northern cold regions to prevent heating capacity attenuation in frigid winter. The system integrates an online AOT disinfection module to restrain legionella breeding in pipelines in real time without chemical additives, complying with sanitary codes for water supply and drainage in hospital buildings. The whole hospital's water pipelines are divided into independent circulation systems by functional zones, with separate temperature control and water return for operating rooms, obstetric wards, general wards and fever clinics. Equipped with pressure-bearing insulated water tanks, circulating return pumps, water pretreatment equipment and intelligent electric control system, as well as electric heating backup heat source, the heat pumps adopt redundant configuration of multiple units in parallel, so maintenance of a single unit will not cut off hot water supply. It is widely used in general hospitals, health and rehabilitation care centers and physical examination medical institutions.
